Orchard Series
Tough. Efficient. Effortless.
The Mahindra Orchard Series Tractors, powered by reliable turbocharged engines and rugged transmissions, are designed for fruit farming applications. With high lifting capacity, versatile speeds, and an ergonomic design, these tractors promise superior performance and
endurance across various agricultural tasks in orchards and vineyards.
Mahindra Orchard Series Tractors
- 5660 V (most popular option)
- 6675 F
Key Features Summary:
- Turbocharged Engines – 57-75 HP with torque levels of 203-310 Nm.
- 8F/8R or 16F/8R Transmission for versatile speeds.
- Twin Speed PTO 540/540e RPM with Independent PTO.
- Heavy-duty 4WD system for demanding applications.
- Ergonomically designed for orchard work.
- High Lift Capacity – 2200/2800 Kg.
Ideal for Various Applications:
Orchards
Haulage
Weeding & Spraying Applications
New Vineyards
Fruit Farming Applications
SPECIFICATION
| ENGINE | 5660V | 6675 F |
|---|---|---|
| Maximum HP | 57.5 (42.3 kW) | 74.4 (54,7 kW) |
| Engine Type | SNK 3100-FLT | Perkins 1104D-44T |
| Engine Speed to Achieve Maximum Speed | 2100 | 2200 |
| Number of Cylinders / Aspiration | 3 / Turbo Intercooler | 4 / Turbo |
| Cylinder Volume (Lt) | 2.78 | 4.4 |
| Maximum Torque | 230 | 307 |
| Engine Speed to Achieve Maximum Torque | 1300 | 1400 |
| Fuel Tank (Lt) | 40 | 70 |
| Emission Level | Tier 3 Stage A | Tier 3 Stage A |
| TRANSMISSION | ||
|---|---|---|
| Type | Carraro T50 | ZF T-537 |
| Gear Box | 8 Front – 8 Rear | 16 Front – 8 Rear |
| Number of Gears / Speeds | 8 Forward, 8 Reverse / 2.35 – 31km/h | 16 Forward, 8 Reverse |
| HYDRAULIC SYSTEM | ||
|---|---|---|
| Type | Mechanical with Draft | Mechanical with Draft |
| Three Point Linkage | Category 2 Compatible | Category 2 Compatible |
| Lift Capacity (Kg) | 2200 | 2800 |
| Rear Auxiliary Remote Valves | 1 Valve as Standard (2 outlets) | 2 Valves as Standard (4 outlets) |
| Type | Independent | Independent |
| PTO Speed (RPM) | 540 | 540/540E rpm |
| Length (mm) | 3773 | 4140 |
| Width (mm) | 1447 | 1680 |
| Wheelbase (mm) | 2045 | 2250 |
| Total (Kg) | 2380 | 2800 |
| Front | 280/70 R18 | 280/70 R16 |
| Rear | 13,6 X 28 | 380/70 R24 |
UNIQUE SELLING POINT
Efficiency Boost
Designed for optimized power, lower fuel consumption, and increased productivity with torque levels up to 310 Nm.
Offers efficient operation with various implements through 540 & 540E speeds and an independent PTO lever
Reduces power losses and ensures improved brake efficiency for higher reliability.
Tough Build & Advanced Features
Equipped with rear axle oil-cooled disc brakes, inboard planetary reduction units, and a flexible front axle for improved maneuverability.
Sturdy 3-point linkage with easy implement hookup, standard auxiliary valves for heavy hydraulic implements, and high-pressure hydraulics for lifting loads up to 2800 kg.
Tough Machines with Superior Performance
Powered by a reliable Perkins 4-cylinder turbocharged engine, delivering superior power and torque for high productivity in various applications.
Equipped with a robust engine and features for tough terrains, offering stability and high lifting capacity.
Effortless Operation & Ergonomics
ZF T-537 transmission with 16F+8R speeds for versatile operation and a dry dual mechanically controlled clutch for durability.
Ergonomic design for narrow areas, foldable ROPS for low height orchards, and sufficient ground clearance for uneven surfaces.
