8600 Series
Tough. Efficient. Effortless.
The Mahindra 8600 Series Tractors are purpose-built for dryland farming, livestock, and dairy applications. They boast a powerful Perkins engine, ZF transmission, and advanced features for maximum efficiency, comfort, and versatility. With a high lifting capacity of 5000 kg and working speeds up to 39.30 km/hr, these tractors are designed to excel in various agricultural tasks.
Mahindra 8600 Series Tractors
- 86-110 P
Key Features Summary:
- 4-Cylinder Turbocharged Intercooled Engine – 110 HP.
- 18.2% Back-Up Torque with 416 Nm Torque @ 1400 Rpm.
- 16F / 16 R ZF Transmission for versatile speeds.
- Independent Four Speed Electro-hydraulic PTO Control.
- Heavy-Duty 4WD system for demanding applications.
- Ergonomically Designed Cabin for operator comfort.
- High Lift Capacity – 5000 Kg.

Ideal for Various Applications:

Hay & Forage

Haulage

Livestock

Dairy

Dry Land Farming
SPECIFICATION
ENGINE | 86-110 P |
---|---|
EMISSIONS | Stage III-B (Interim Tier 4) |
MODEL | PERKINS 1104D-44TA Turbocharged & Intercooled |
POWER | 110 HP @ 2200 RPM |
PTO POWER | 85% of Engine Power |
MAX SPEED | 2400 RPM |
TORQUE | 416Nm @ 1400 RPM |
ASPIRATION | Turbocharged, Intercooled |
AIR FILTER | Dry Tape With Pre-Internal Filter |
BORE X STROKE | 99 mm x 110 mm |
CYLINDERS | 4 |
CYLINDERS-CUBIC CAPACITY (CC) | 4400 cc |
CLUTCH | |
---|---|
TYPE | Duel |
TRANSMISSION | |
TYPE | Power Shift Hi-Lo |
NUMBER OF GEARS / SPEEDS | 16 Forward & 16 Reverse |
PTO SHAFT | |
---|---|
TYPE | Independent Electro Hydrailic |
SPEED | 540-540E |
HYDRAULICS | |
---|---|
TYPE | Electronical |
THREE POINT LINKAGE | Cat II |
CONTROL | Electro-Hydraulic |
LIFT CAPACITY | 5000 Kg |
REAR AUXILARY REMOTE VALVES | 4 Spool |
OTHER | |
---|---|
DRIVE SYSTEM | 4WD |
STEERING | Hydrostatic Power Steering |
BRAKE TYPE | Oil Immersed Brake |
ELECTRICAL | |
---|---|
BATTERY CAPACITY | 12V, 115Ah |
ALTERNATOR | 120 A |
DIMENSIONS | |
---|---|
LENGTH | 4455 mm |
WHEELBASE | 2405 mm |
WIDTH | 2030 mm |
UNIQUE SELLING POINT
Effortless Operator Comfort & Advanced Features
Loaded with comfort features like an adjustable operator seat, easy access controls, and illumination for enhanced comfort during long hours. Air-conditioned cabin with radio/CD player for a superior working experience.
ZF T-557 L transmission with 16F+16R speeds for smooth shifting and maximum performance in varied applications. Features a power shift, button-activated differential lock, and Synchromesh transmission for broad application range.
Efficiency Redefined
Engineered for reduced fuel consumption and extended engine component life.
Independent PTO lever for easy engagement and disengagement, offering economy speeds for versatile implement operation.
Four-wheel-drive lever with electronic activation for enhanced efficiency and reduced slipping in rough terrain.
Ease of Operation
Standard 12F + 12R driving speeds and a forward/reverse shuttle for maximum productivity during intense operations.
Spacious platform design, adjustable seats, and ergonomic controls for operator comfort, equipped with durable components for long-lasting performance.
Offers 540 & 1000 speeds with ease of engagement and disengagement for various implement operations.
Unmatched Power & Capacity
- Perkins 4-cylinder turbocharged intercooler engine delivering exceptional power, fuel efficiency, and reliability. High torque levels ensure productivity in various applications.
Equipped with 4 sets of standard auxiliary valves and a high-pressure hydraulic system capable of lifting loads up to 5000 kg. Automatic Lifting System (ALS) for efficient implement control.
