7500 Series

Tough. Efficient. Effortless.

The Mahindra 7500 Series Tractors combine modern styling with high performance, featuring a robust engine, heavy-duty transmission, and impressive lift capacity.

Designed for reliability and ease of operation, these tractors excel in various agricultural applications, from soil tilling to haulage, promising exceptional performance across diverse terrains and tasks.

Mahindra 7500 Series tractors

  • 7580 2WD
  • 7590 4WD

Key Features Summary:

  • Turbocharged 4-cylinder engine delivering 80-92 HP.
  • High maximum torque for enhanced power.
  • 12F + 12R Synchromesh transmission with Synchro Shuttle Shift Technology.
  • Dual PTO speeds with independent control.
  • Heavy-duty 4WD system for demanding applications.
  • Full platform design with ergonomic features.
recision Agriculture, High-Performance Farm Machinery, Precision Equipment Solutions

Ideal for Various Applications:

Agriculture

Hay

Livestock

Ground Maintenance/ Municipal

SPECIFICATION

ENGINE7580 2WD7580 4WD7590 2WD7590 4WD
TypeFour Stroke, Direct Injection, Turbocharged & Inter Cooled, Water Cooled, Diesel EngineFour Stroke, Direct Injection, Turbocharged & Inter Cooled, Water Cooled, Diesel EngineFour Stroke, Direct Injection, Turbocharged & Inter Cooled, Water Cooled, Diesel EngineFour Stroke, Direct Injection, Turbocharged & Inter Cooled, Water Cooled, Diesel Engine
Cylinders4444
Engine HP @ RPM80 HP @ 230080 HP @ 230092 HP @ 230092 HP @ 2300
Displacement Cubic (CC)3533



ELECTRICAL
Battery Capacity12 V. 88 AH12 V. 88 AH12 V. 88 AH12 V. 88 AH
Alternator12 V. 55 A12 V. 55 A12 V. 55 A12 V. 55 A



CLUTCH
TypeDual ClutchDual ClutchDual ClutchDual Clutch



TRANSMISSION
TypeForward – Reverse Shuttle With Synchromesh Gear ShiftForward – Reverse Shuttle With Synchromesh Gear ShiftForward – Reverse Shuttle With Synchromesh Gear ShiftForward – Reverse Shuttle With Synchromesh Gear Shift
Number Of Gears/Speeds12 Forward, 12 Reverse12 Forward, 12 Reverse12 Forward, 12 Reverse12 Forward, 12 Reverse



STEERING
TypeHydrostatic Power SteeringHydrostatic Power SteeringHydrostatic Power SteeringHydrostatic Power Steering



BRAKES
TypeOil ImmersedOil ImmersedOil ImmersedOil Immersed



HYDRAULIC SYSTEM
TypeOpen Center, Full-live Hydraulic With Position & Draft ControlsOpen Center, Full-live Hydraulic With Position & Draft ControlsOpen Center, Full-live Hydraulic With Position & Draft ControlsOpen Center, Full-live Hydraulic With Position & Draft Controls
3-Point LinkageCAT II Linkages With Stabiliser BarCAT II Linkages With Stabiliser BarCAT II Linkages With Stabiliser BarCAT II Linkages With Stabiliser Bar
Lift Capacity (Kg)2500250025002500
Rear Auxiliary Remote ValvesDoubleDoubleDoubleDouble
PTO
TypeIndependent PTOIndependent PTOIndependent PTOIndependent PTO
PTO RPM (Engine RPM)540 @ 2186 / 1000 @ 2180540 @ 2186 / 1000 @ 2180540 @ 2186 / 1000 @ 2180540 @ 2186 / 1000 @ 2180
PTO HP65657474
OPERATING WEIGHT
Total (Kg)3508369835083698
DIMENSIONS WITH AG TYRES
Overall Length (mm)4115411541154115
Overall Width (mm)1963196319631963



TYRE SIZES & OPTIONS
AG (Front/Rear)7.5 x 16 / 10.0 x 16 (Opt) / 16.9 x 30 / 18.4 x 30 (Opt)11.2 x 24 / 12.4 x 24 (Opt) / 16.9 x 30 / 18.4 x 30 (Opt)10.0 x 16 / 18.4 x 3012.4 x 24 / 18.4 x 30



Unique Selling Point

Ease of Operation

Standard 12F + 12R driving speeds and a forward/reverse shuttle for maximum productivity during intense operations.

Spacious platform design, adjustable seats, and ergonomic controls for operator comfort, equipped with durable components for long-lasting performance.

Offers 540 & 1000 speeds with ease of engagement and disengagement for various implement operations.

Efficiency Reinvented

Turbocharged for peak power and efficiency. Engineered with a low rated speed of 2300 RPM to reduce fuel consumption and enhance engine longevity, supported by an efficient cooling system

Independent PTO lever for seamless engagement and disengagement during all PTO-driven applications.

Ensures low power losses, improved brake efficiency, and high reliability for superior performance.

Unmatched Toughness

Provides exceptional grip and handling in tough terrains, with 15-20% more weight compared to most competition models.

Standard ROPS structure designed to protect the operator and meet stringent safety standards.

Superior lifting capacity up to 2500 KG, enabling handling of heavy implements with ease.

Power-Packed Features

Boasts a powerful turbocharged engine generating high torque and a class-leading power output of 80-92 HP.

Equipped with a heavy-duty front axle and powerful hydraulics for superior performance in demanding conditions

Synchromesh transmission with shuttle shift technology for smooth operation and increased efficiency.
